LTM 204HP

small tractor:20HP -60HP

Power Range: Farm tractor 20-60HP
Model : 254,304, 354,404,454,504,604
Diesel Engine: 2,3,4 Cylinder Diesel Engine
Drive Method: 4WD
Tyre size: 6.0-16/9.5-24; 7.5-16/11.2-24
Transmission Method: Shaft Transmission
Clutch: Single Stage Clutch/Double Stage Clutch
Gearbox:(4+1)*2
Steering Method: Mechanical Steering and Hydraulic Steering Optional
color: as you like
cabin:heat and fan cabin
PTO Speed: 540/760 r/min Optional
Package: a 20ft container can hold 8 sets in steel frame package, 2sets in complete package
a 40 hq container can hold 16 sets in steel frame package, 4 sets in complete package

Quantity:
Availability:





Inquire Add to Basket

Model:
LTM 204
Brand:
LTM

Product Description

small tractor-TY model

Products model	TY254	TY 304	TY 404	TY 504
Wheel drive	4x4 Wheel type
LWH(mm)	3350x1500x1860
Weight(KG)	1250-1380
Front wheel tread(mm)	850,960,1000,1100,1200,1300, adjustable
Rear wheel tread(mm)	960-1300 unlimited adjustable
Minimum clearance	330(340)
Tyre size	6.0-16/9.5-24
Gear Shifts	8+2(8+8)
Engine Brand	Lai Dong diesel engine
Type	Water cooled, Vertical,4 stroke and direct injection
Rated power(kw)	18.3	22.6	29.4	36.7
Rated revolution(r/m)	2300/2400
Transmission box	(4+1)x2 shifts
Clutch	Single chip,Dry friction and single& double stage clutch
Start way	Electric start
PTO	6 spline/540/720RPM or 540/760RPM
Suspension	Three point linkage/II level
Optional configuration	Ropes &sunshade/ Balanced weight/ valves/ Luxury seat

small tractor-TE model

Products model	TE-404	TE-454	TE-504	TE-604
Wheel drive	4x4 Wheel type
LWH(mm)	3450x1550x1860
Weight(KG)	1350-1500
Front wheel tread(mm)	850,960,1000,1100,1200,1300, adjustable
Rear wheel tread(mm)	960-1300 unlimited adjustable
Wheel base(mm)	1750
Minimum clearance	330(340)
Tyre size	6.5-16/9.5-24(Optional : 7.5-16/11.2-24)
Gear Shifts	8+2(8+8)
Engine Brand	LDdiesel engine
Type	Water cooled, Vertical,4 stroke and direct injection
Rated power(kw)	29.4	33.1	36.7	44.1
Rated revolution(r/m)	2300/2400
Transmission box	(4+1)x2 shifts or (4+4)x2
Clutch	Single chip,Dry friction and single& double stage clutch
Start way	Electric start
PTO	6 spline/540/720RPM or 540/760RPM
Suspension	Three point linkage/I level
Optional configuration	Ropes&sunshade/valves/ Luxury seat/Flat Tyre etc
