Disc Mower

· Have features a bi-shaft design with each disc self-contained and pre-packed with its own set of gears,bearings and lubricants to increase operating life.

· Add in heavier cutting discs,super-sized skid shoes.

· Two high-quality, reversible knives per disc on four, five or six oval cutting discs.

· Rock guards and skid shoes to protect discs and carry the cutterbar over uneven ground.

· An enclosed gear-driven cutterbar that provides years of reliable service.

· Adjustable flotation springs for changing cutterbar ground pressure.

· A spring-loaded breakaway latch that protects the cutterbar.

· A single-acting hydraulic cylinder that easily lifts the cutterbar after each pass.

· An articulation joint that allows mowers to operate above and below horizontal.

Quantity:
Availability:





Inquire Add to Basket

Brand:
LTM

Product Description

Model	DM1300	DM1700	DM2100	DM2500
Working Width (mm)	1300	1700	2050	2400
Number of Disc (Pcs)	3	4	5	6
Length (mm)	2850	3250	3650	4050
Width (mm)	1640
Height (mm)	875
Working Speed (km/h)	4-10
Matched Power (hp)	20-50	35-80	40-80	50-100
Linkage	Three Point Mounted, Category I or II

spring-loaded hydraulic cylinder cutterbar gear-driven single-acting
