LTM
Model | 1GLN-85 | 1GLN-105 | 1GLN-125 | 1GLN-135 | 1GLN-150 | 1GLN-160 |
Working Width (mm) | 850 | 1045 | 1245 | 1345 | 1495 | 1595 |
Working Depth (mm) | 120 | |||||
PTO Speed (r/min) | 540 | |||||
Number of Disc (Pcs) | 20 | 20 | 24 | 28 | 32 | 36 |
Linkage | Three Point Mounted | |||||
Matched Power (hp) | 12~20 | 20-30 | 25-35 | 30-40 | 30-45 | 40-50 |
Model | 1GLN-165 | 1GLN-180 | 1GLN-200 | 1GLN-210 | 1GLN-220 | 1GLN-230 |
Working Width (mm) | 1645 | 1750 | 1950 | 2050 | 2150 | 2250 |
Working Depth (mm) | 120-160 | |||||
PTO Speed (r/min) | 540 | |||||
Number of Disc (Pcs) | 36 | 44 | 52 | 56 | 60 | 64 |
Linkage | Three Point Mounted | |||||
Matched Power (hp) | 50-80 | 50-80 | 55-85 | 60-85 | 65-85 | 70-90 |
Model | 1GLN-85 | 1GLN-105 | 1GLN-125 | 1GLN-135 | 1GLN-150 | 1GLN-160 |
Working Width (mm) | 850 | 1045 | 1245 | 1345 | 1495 | 1595 |
Working Depth (mm) | 120 | |||||
PTO Speed (r/min) | 540 | |||||
Number of Disc (Pcs) | 20 | 20 | 24 | 28 | 32 | 36 |
Linkage | Three Point Mounted | |||||
Matched Power (hp) | 12~20 | 20-30 | 25-35 | 30-40 | 30-45 | 40-50 |
Model | 1GLN-165 | 1GLN-180 | 1GLN-200 | 1GLN-210 | 1GLN-220 | 1GLN-230 |
Working Width (mm) | 1645 | 1750 | 1950 | 2050 | 2150 | 2250 |
Working Depth (mm) | 120-160 | |||||
PTO Speed (r/min) | 540 | |||||
Number of Disc (Pcs) | 36 | 44 | 52 | 56 | 60 | 64 |
Linkage | Three Point Mounted | |||||
Matched Power (hp) | 50-80 | 50-80 | 55-85 | 60-85 | 65-85 | 70-90 |
