LTM 100HP tractor

• Gearbox: Standard configuration: 12F+12R synchro shift; optiois:16F+8R synchro shift
speed synchronized shift is optional and it has features like energy saving, reliable and comfortable.
• Driving Cab:Standard configuration is RO PS and cab ,and compatible configurations with European design, fully-wrapped
interior, steering wheel adjustable fore and aft, car air conditioning system and luxurious seat which fully improves the control
comfort.
• Clutch: Standard configuration 11-12 inch dual clutch is equipped with a friction disk made of special ceramic material with high
reliability.
• Tires : Paddy land tires, OTR tires, meadow tires are optional.
• Electronic system: Taking rainy and humid environments intc consideration, it is equipped with electrical wirings and connectors
with high sealing performance so as to extend the service life of the electronic system.
• Floor: flat floor, side-placed operating lever and suspension pedal are optional .which improves controcomfort
Availability:
Quantity:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
kakao sharing button
snapchat sharing button
sharethis sharing button
  • LTM 1004HP

  • LTM





   Tractor

Parameter



Model

1004

Drive Type

4WD

Overall Dimensions L×W×H(mm):

3980x1760x2800

Wheel Bass(mm)

2052

Ground Clearance (mm)

308

Rated Traction Force(N)

9800

Construction Mass(kg)

2200

Theoretical Speed (km/h)


Forward

2.46—32.73

Reverse

2.15—28.69

     Engine
Specifications

Type

4-Cylinder Vertical,water cooled,4 stroke cycle

Rated Power(kw/hp)

73.5/100

Rated Speed (rpm)

2400

Drive
System


Clutch

11" dual-stage

Gear Box

(1+1)×4x3



   Traveling
Mechanism



Tyre


Front

280/85R20

Rear

420/85R28

Steering Gear

Full Hydraulic Steering

Brake

Disc type

Working
Device




Hydraulic System


Lifting Capacity at 610mm Behind Lift Point (N)

11000

3-Point Suspension

Category:I

P.T.O Shaft


Rotating
Speed (rpm)

540/1000

Spline Size

6-35Rectangular Spline
