LTM 604HP
LTM
QUOTATION LIST FOR 604 TRACTOR
Tractor Parameters | Model | 604 | |
Drive Type | 4WD | ||
Overall Dimensions L×W×H(mm): | 3980x1760x2800 | ||
Wheel Track (mm) | Front | 1400/1450/1500/1550 | |
Rear | 1300-1800 | ||
Wheel Bass(mm) | 2010 | ||
Ground Clearance (mm) | 308 | ||
Rated Traction Force(N) | 13000 | ||
Construction Mass(kg) | 2900 | ||
Theoretical Speed (km/h) | Forward | 2.46—32.73 | |
Reverse | 2.15—28.69 | ||
Engine Specifications | Model | ||
Type | 4-Cylinder Vertical,water cooled,4 stroke cycle | ||
Rated Power(kw/hp) | 51.5/70 | ||
Rated Speed (rpm) | 2400 | ||
Bore×Stroke (mm) | 90×100 | ||
Total Displacement(L) | 2.8 | ||
Drive System | Clutch | 11" dual-stage | |
Gear Box | 12F+12R | ||
Traveling Mechanism | Tyre | Front | 280/85r20 |
Rear | 420/85r28 | ||
Steering Gear 转向 | Full Hydraulic Steering | ||
Brake制动 | Disc type | ||
Working Device | Hydraulic System | Lifting Capacity at 610mm Behind Lift Point (N) | 11000 |
3-Point Suspension | Category:II | ||
P.T.O Shaft | Rotating Speed (rpm) | 540/1000 | |
Spline Size | 6-∮35Rectangular Spline | ||
QUOTATION LIST FOR 604 TRACTOR
Tractor Parameters | Model | 604 | |
Drive Type | 4WD | ||
Overall Dimensions L×W×H(mm): | 3980x1760x2800 | ||
Wheel Track (mm) | Front | 1400/1450/1500/1550 | |
Rear | 1300-1800 | ||
Wheel Bass(mm) | 2010 | ||
Ground Clearance (mm) | 308 | ||
Rated Traction Force(N) | 13000 | ||
Construction Mass(kg) | 2900 | ||
Theoretical Speed (km/h) | Forward | 2.46—32.73 | |
Reverse | 2.15—28.69 | ||
Engine Specifications | Model | ||
Type | 4-Cylinder Vertical,water cooled,4 stroke cycle | ||
Rated Power(kw/hp) | 51.5/70 | ||
Rated Speed (rpm) | 2400 | ||
Bore×Stroke (mm) | 90×100 | ||
Total Displacement(L) | 2.8 | ||
Drive System | Clutch | 11" dual-stage | |
Gear Box | 12F+12R | ||
Traveling Mechanism | Tyre | Front | 280/85r20 |
Rear | 420/85r28 | ||
Steering Gear 转向 | Full Hydraulic Steering | ||
Brake制动 | Disc type | ||
Working Device | Hydraulic System | Lifting Capacity at 610mm Behind Lift Point (N) | 11000 |
3-Point Suspension | Category:II | ||
P.T.O Shaft | Rotating Speed (rpm) | 540/1000 | |
Spline Size | 6-∮35Rectangular Spline | ||
